Series:70×70×30MM
-
Material:Housing Plastic (UL: 94V-0)
Impeller Plastlc (UL: 94V-0)
-
Bearing Type:Two ball bearing
-
Protection:Auto-Restart /Impedance
-
Rated Voltage:12V
-
Operating Temp:~10~70℃
-
Weight:85g
7530
基本信息
图片展示
型号
| Model | Rated Voltage (V) | Operating Voltage Range(V) | Rated Current (Amp) | Rated Input Power(W) | Rated Speed (rpm) | Air Flow | Static Pressure (mmH2O) | Sound level dB(A) | |
|---|---|---|---|---|---|---|---|---|---|
| (CFM) | m3/min | ||||||||
| XHB075301BL | 12 | 7~13.2 | 0.18 | 2.16 | 2050 | 7.01 | 0.20 | 5.40 | 26.7 |
| XHB075301BL | 12 | 7~13.2 | 0.20 | 2.40 | 2400 | 8.21 | 0.23 | 7.40 | 31.5 |
| XHB075301BL | 12 | 7~13.2 | 0.30 | 3.60 | 2900 | 9.92 | 0.28 | 10.81 | 35.6 |
| XHB075301BL | 12 | 7~13.2 | 0.42 | 5.04 | 3300 | 11.29 | 0.32 | 14.00 | 38.7 |
NOTES:"X"="B"
*Sound level measured at the distance of one meter from the axis of intake.
*Specifications are subject change without notice.
