Series:70×70×15MM
-
Material:Housing Plastic (UL: 94V-0)
Impeller Plastlc (UL: 94V-0)
-
Bearing Type:Two ball bearing
-
Protection:Auto-Restart /Impedance
-
Rated Voltage:12V
-
Operating Temp:~10~70℃
-
Weight:42g
7015
基本信息
图片展示
型号
| Model | Rated Voltage (V) | Operating Voltage Range(V) | Rated Current (Amp) | Rated Input Power(W) | Rated Speed (rpm) | Air Flow | Static Pressure (mmH2O) | Sound level dB(A) | |
|---|---|---|---|---|---|---|---|---|---|
| (CFM) | m3/min | ||||||||
| XHB070151BL | 12 | 7~13.2 | 0.16 | 1.92 | 3600 | 7.41 | 0.21 | 12.49 | 46.4 |
| XHB070151BL | 12 | 7~13.2 | 0.20 | 2.40 | 4200 | 8.73 | 0.25 | 17.87 | 51.6 |
| XHB070151BL | 12 | 7~13.2 | 0.40 | 4.80 | 4800 | 10.05 | 0.28 | 25.36 | 54.0 |
| XHB070151BL | 12 | 7~13.2 | 0.50 | 6.00 | 5400 | 11.32 | 0.32 | 36.86 | 57.0 |
NOTES:"X"="B"
*Sound level measured at the distance of one meter from the axis of intake.
*Specifications are subject change without notice.
