Series:50×50×20MM
-
Material:Housing Plastic (UL: 94V-0)
Impeller Plastlc (UL: 94V-0)
-
Bearing Type:Two ball bearing EBR
-
Protection:Auto-Restart /Impedance
-
Rated Voltage:12V
-
Operating Temp:~10~70℃
-
Weight:33g
5020
基本信息
图片展示
型号
| Model | Rated Voltage (V) | Operating Voltage Range(V) | Rated Current (Amp) | Rated Input Power(W) | Rated Speed (rpm) | Air Flow | Static Pressure (mmH2O) | Sound level dB(A) | |
|---|---|---|---|---|---|---|---|---|---|
| (CFM) | m3/min | ||||||||
| XHA050201BM | 12 | 7~13.2 | 0.20 | 2.4 | 5000 | 16.33 | 0.46 | 4.14 | 29 |
| XHA050201BM | 12 | 7~13.2 | 0.35 | 4.2 | 6000 | 19.60 | 0.56 | 5.96 | 33.2 |
| XHA050201BM | 12 | 7~13.2 | 0.55 | 6.6 | 7000 | 22.86 | 1.65 | 8.12 | 37.2 |
| XHA050201BM | 12 | 7~13.2 | 0.70 | 8.4 | 8000 | 26.13 | 0.74 | 10.60 | 42.8 |
NOTES:"X"="B"
*Sound level measured at the distance of one meter from the axis of intake.
*Specifications are subject change without notice.
