Series:50×50×15MM
-
Material:Housing Plastic (UL: 94V-0)
Impeller Plastlc (UL: 94V-0)
-
Bearing Type:Two ball bearing EBR
-
Protection:Auto-Restart /Impedance
-
Rated Voltage:12V
-
Operating Temp:~10~70℃
-
Weight:30g
5015
基本信息
图片展示
型号
| Model | Rated Voltage (V) | Operating Voltage Range(V) | Rated Current (Amp) | Rated Input Power(W) | Rated Speed (rpm) | Air Flow | Static Pressure (mmH2O) | Sound level dB(A) | |
|---|---|---|---|---|---|---|---|---|---|
| (CFM) | m3/min | ||||||||
| XHA050151BM | 12 | 7~13.2 | 0.20 | 2.40 | 5000 | 11.97 | 0.34 | 3.08 | 26.5 |
| XHA050151BM | 12 | 7~13.2 | 0.25 | 3.00 | 6000 | 14.36 | 0.41 | 4.44 | 30.2 |
| XHA050151BM | 12 | 7~13.2 | 0.32 | 3.84 | 7000 | 16.76 | 0.47 | 6.05 | 35.3 |
| XHA050151BM | 12 | 7~13.2 | 0.60 | 7.20 | 8000 | 19.15 | 0.54 | 7.90 | 39.3 |
NOTES:"X"="B"
*Sound level measured at the distance of one meter from the axis of intake.
*Specifications are subject change without notice.
