Series:80×80×56MM
-
Material:Housing Plastic (UL: 94V-0)
Impeller Plastlc (UL: 94V-0)
-
Bearing Type:Two ball bearing
-
Protection:Auto-Restart
-
Rated Voltage:12V
-
Operating Temp:~10~70℃
-
Weight:134g
20060
基本信息
图片展示
型号
| Model | Rated Voltage (V) | Operating Voltage Range(V) | Rated Current (Amp) | Rated Input Power(W) | Rated Speed (rpm) | Air Flow | Static Pressure (mmH2O) | Sound level dB(A) | |
|---|---|---|---|---|---|---|---|---|---|
| (CFM) | m3/min | ||||||||
| XHA200601BL | 12 | 7~14 | 0.80 | 9.60 | 1600 | 292 | 8.26 | 5.90 | 42.0 |
| XHA200601BL | 12 | 7~14 | 1.70 | 20.40 | 2200 | 401 | 11.35 | 11.16 | 50.5 |
| XHA200601BL | 12 | 7~14 | 0.40 | 9.60 | 1600 | 292 | 8.26 | 5.90 | 42.0 |
| XHA200601BL | 24 | 15~27 | 0.90 | 21.60 | 2200 | 401 | 11.35 | 11.16 | 50.5 |
NOTES:"X"="B"
*Sound level measured at the distance of one meter from the axis of intake.
*Specifications are subject change without notice.
